Valtec brass T-pieces for multilayer pipes

Home→ Catalog→ VALTEC→ Multilayer systems→ T-pieces

A T-piece is a special fitting wich is designed for connection of three pipes to each other.

Valtec T-pieces can be divided into several types:

  • Equal - this type of fitting allows to connect pipes with the same diameter.
  • Reducer - this fittings are used to connect pipes with different diameters.
  • Threaded - T-pieces are equipped with male or female thread which is corresponding to GOST.

The body of the T-pieces is made of plumbing brass CW617N, the sealing rings are made of EPDM, the press sleeves are made of stainless steel.

Valtec T-pieces, which are connected by pressing, provide high throughput, are characterized by reliability of joints, durability and heat resistance. Special tools with “TH” type jaws are used for mounting.

Photo Наименование Article Цена
Photo Draft
Photo VALTEC T-piece, pressing connection, with male thread, d - 16х1/2" [Code number: VTm.333.N.160416] Draft VALTEC T-piece, pressing connection, with male thread, d - 16х1/2" [Code number: VTm.333.N.160416]
VALTEC T-piece, pressing connection, with male thread, d - 16х1/2" [Code number: VTm.333.N.160416]
Details 		VTm.333.N.160416 430 rub

Application purpose:

  • For drinking and domestic water supply systems
  • For hot water
  • For heating
  • For connection metal-polymer pipes

Characteristics:

  • Housing made of hot stamped (GOSH) nickel-plated brass grade CW617N to EN 12165
  • EPDM O-rings
  • Male thread in accordance with GOST 6357
  • Nominal pressure 25 bar
  • Operating pressure 10 bar
  • The maximum temperature of working environment is up to +115 ºС
  • The minimum temperature of working environment is up to -30 ºС
  • Average life of 50 years



D1 D2 D3 А В Weight
  mm mm mm mm kg/pc
1/2" 16 16 65 27,5 0,132

Download data sheet: VALTEC Compression fittings
Photo Draft
Photo VALTEC T-piece, pressing connection, with male thread, d - 20х1/2" [Code number: VTm.333.N.200420] Draft VALTEC T-piece, pressing connection, with male thread, d - 20х1/2" [Code number: VTm.333.N.200420]
VALTEC T-piece, pressing connection, with male thread, d - 20х1/2" [Code number: VTm.333.N.200420]
Details 		VTm.333.N.200420 696 rub

Application purpose:

  • For drinking and domestic water supply systems
  • For hot water
  • For heating
  • For connection metal-polymer pipes

Characteristics:

  • Housing made of hot stamped (GOSH) nickel-plated brass grade CW617N to EN 12165
  • EPDM O-rings
  • Male thread in accordance with GOST 6357
  • Nominal pressure 25 bar
  • Operating pressure 10 bar
  • The maximum temperature of working environment is up to +115 ºС
  • The minimum temperature of working environment is up to -30 ºС
  • Average life of 50 years



D1 D2 D3 А В Weight
  mm mm mm mm kg/pc
1/2" 20 20 77 27,5 0,240

Download data sheet: VALTEC Compression fittings
Photo Draft
Photo VALTEC T-piece, pressing connection, with male thread, d - 20х3/4" [Code number: VTm.333.N.200520] Draft VALTEC T-piece, pressing connection, with male thread, d - 20х3/4" [Code number: VTm.333.N.200520]
VALTEC T-piece, pressing connection, with male thread, d - 20х3/4" [Code number: VTm.333.N.200520]
Details 		VTm.333.N.200520 671 rub

Application purpose:

  • For drinking and domestic water supply systems
  • For hot water
  • For heating
  • For connection metal-polymer pipes

Characteristics:

  • Housing made of hot stamped (GOSH) nickel-plated brass grade CW617N to EN 12165
  • EPDM O-rings
  • Male thread in accordance with GOST 6357
  • Nominal pressure 25 bar
  • Operating pressure 10 bar
  • The maximum temperature of working environment is up to +115 ºС
  • The minimum temperature of working environment is up to -30 ºС
  • Average life of 50 years



D1 D2 D3 А В Weight
  mm mm mm mm kg/pc
3/4" 20 20 77 31,5 0,244

Download data sheet: VALTEC Compression fittings
Photo Draft
Photo VALTEC T-piece, pressing connection, with male thread, d - 26х3/4" [Code number: VTm.333.N.260526] Draft VALTEC T-piece, pressing connection, with male thread, d - 26х3/4" [Code number: VTm.333.N.260526]
VALTEC T-piece, pressing connection, with male thread, d - 26х3/4" [Code number: VTm.333.N.260526]
Details 		VTm.333.N.260526 982 rub

Application purpose:

  • For drinking and domestic water supply systems
  • For hot water
  • For heating
  • For connection metal-polymer pipes

Characteristics:

  • Housing made of hot stamped (GOSH) nickel-plated brass grade CW617N to EN 12165
  • EPDM O-rings
  • Male thread in accordance with GOST 6357
  • Nominal pressure 25 bar
  • Operating pressure 10 bar
  • The maximum temperature of working environment is up to +115 ºС
  • The minimum temperature of working environment is up to -30 ºС
  • Average life of 50 years



D1 D2 D3 А В Weight
  mm mm mm mm kg/pc
3/4" 26 26 88 35 0,303

Download data sheet: VALTEC Compression fittings
Photo Draft
Photo VALTEC T-piece, pressing connection, with male thread, d - 26х1" [Code number: VTm.333.N.260626] Draft VALTEC T-piece, pressing connection, with male thread, d - 26х1" [Code number: VTm.333.N.260626]
VALTEC T-piece, pressing connection, with male thread, d - 26х1" [Code number: VTm.333.N.260626]
Details 		VTm.333.N.260626 975 rub

Application purpose:

  • For drinking and domestic water supply systems
  • For hot water
  • For heating
  • For connection metal-polymer pipes

Characteristics:

  • Housing made of hot stamped (GOSH) nickel-plated brass grade CW617N to EN 12165
  • EPDM O-rings
  • Male thread in accordance with GOST 6357
  • Nominal pressure 25 bar
  • Operating pressure 10 bar
  • The maximum temperature of working environment is up to +115 ºС
  • The minimum temperature of working environment is up to -30 ºС
  • Average life of 50 years



D1 D2 D3 А В Weight
  mm mm mm mm kg/pc
1" 26 26 88 39 0,324

Download data sheet: VALTEC Compression fittings
Photo Draft
Photo VALTEC T-piece, pressing connection, with male thread, d - 32х1" [Code number: VTm.333.N.320632] Draft VALTEC T-piece, pressing connection, with male thread, d - 32х1" [Code number: VTm.333.N.320632]
VALTEC T-piece, pressing connection, with male thread, d - 32х1" [Code number: VTm.333.N.320632]
Details 		VTm.333.N.320632 2 244 rub

Application purpose:

  • For drinking and domestic water supply systems
  • For hot water
  • For heating
  • For connection metal-polymer pipes

Characteristics:

  • Housing made of hot stamped (GOSH) nickel-plated brass grade CW617N to EN 12165
  • EPDM O-rings
  • Male thread in accordance with GOST 6357
  • Nominal pressure 25 bar
  • Operating pressure 10 bar
  • The maximum temperature of working environment is up to +115 ºС
  • The minimum temperature of working environment is up to -30 ºС
  • Average life of 50 years



D1 D2 D3 А В Weight
  mm mm mm mm kg/pc
1" 32 32 105 42 0,672

Download data sheet: VALTEC Compression fittings
Photo Draft
Photo VALTEC T-piece, pressing connection, with male thread, d - 32х1 1/4" [Code number: VTm.333.N.320732] Draft VALTEC T-piece, pressing connection, with male thread, d - 32х1 1/4" [Code number: VTm.333.N.320732]
VALTEC T-piece, pressing connection, with male thread, d - 32х1 1/4" [Code number: VTm.333.N.320732]
Details 		VTm.333.N.320732 2 634 rub

Application purpose:

  • For drinking and domestic water supply systems
  • For hot water
  • For heating
  • For connection metal-polymer pipes

Characteristics:

  • Housing made of hot stamped (GOSH) nickel-plated brass grade CW617N to EN 12165
  • EPDM O-rings
  • Male thread in accordance with GOST 6357
  • Nominal pressure 25 bar
  • Operating pressure 10 bar
  • The maximum temperature of working environment is up to +115 ºС
  • The minimum temperature of working environment is up to -30 ºС
  • Average life of 50 years



D1 D2 D3 А В Weight
  mm mm mm mm kg/pc
1 1/4" 32 32 105 50 0,870

Download data sheet: VALTEC Compression fittings
