VALTEC threaded elbows

VALTEC threaded elbows are made of high quality brass and are used to connect pipes at angle of 45° and 90°.

Brass is not afraid of rust, so that VALTEC threaded elbows are highly resistant to corrosion. Nickel plating provides additional protection and maintains a decent appearance of products throughout the entire life cycle.

Another advantage of using threaded fittings is low coefficient of linear expansion, so that a hot water pipeline will not be deformation.

The thread is not oxidized which allows dismantling the fittings if necessary.

Nominal pressure 4.0 MPa.

Photo Наименование Article Цена

VALTEC Elbow, female-male, d - 1 1/2" [Code number: VTr.092.N.0008]

Details

VTr.092.N.0008

1 722 rub

Application purpose:

For cold water supply
For hot water
For heating
For domestic water supply systems
For compressed air systems
For technological pipelines
For pipelines transporting gases and liquids, non-aggressive to the fitting material
To create detachable threaded connections

Characteristics:

Thread female-male
Pipe cylindrical thread according to GOST 6357 (ISO 228, EN 10226)
Nominal pressure 17 to 40 bar
Execution material: hot-pressed brass of the CW 617N brand according to the EN 12165 standard
The maximum temperature of a working environment is up to +250 ºС

G	А	B	Weight
	mm	mm	kg/pc
1 1/2"	72	62	0,554

Download data sheet: VALTEC Threaded fittings

VALTEC Elbow, female-male, d - 2" [Code number: VTr.092.N.0009]

Details

VTr.092.N.0009

2 891 rub

Application purpose:

For cold water supply
For hot water
For heating
For domestic water supply systems
For compressed air systems
For technological pipelines
For pipelines transporting gases and liquids, non-aggressive to the fitting material
To create detachable threaded connections

Characteristics:

Thread female-male
Pipe cylindrical thread according to GOST 6357 (ISO 228, EN 10226)
Nominal pressure 17 to 40 bar
Execution material: hot-pressed brass of the CW 617N brand according to the EN 12165 standard
The maximum temperature of a working environment is up to +250 ºС

G	А	B	Weight
	mm	mm	kg/pc
2"	87	73	0,991

Download data sheet: VALTEC Threaded fittings

VALTEC Threaded fitting (elbow for Eurocone), d - 3/4"(EK female), d1 - 3/4"(EK male) [Code number: VTr.092.NE.0505]

Details

VTr.092.NE.0505

306 rub

VALTEC Elbow, male-male, d - 1/2" [Code number: VTr.093.N.0004]

Details

VTr.093.N.0004

192 rub

Application purpose:

For cold water supply
For hot water
For heating
For domestic water supply systems
For compressed air systems
For technological pipelines
For pipelines transporting gases and liquids, non-aggressive to the fitting material
To create detachable threaded connections

Characteristics:

Thread male-male
Pipe cylindrical thread according to GOST 6357 (ISO 228, EN 10226)
Nominal pressure 17 to 40 bar
Execution material: hot-pressed brass of the CW 617N brand according to the EN 12165 standard
The maximum temperature of a working environment is up to +250 ºС

G	А	B	Weight
	mm	mm	kg/pc
1/2"	35	27	0,065

Download data sheet: VALTEC Threaded fittings

VALTEC Elbow, male-male, d - 3/4" [Code number: VTr.093.N.0005]

Details

VTr.093.N.0005

400 rub

Application purpose:

For cold water supply
For hot water
For heating
For domestic water supply systems
For compressed air systems
For technological pipelines
For pipelines transporting gases and liquids, non-aggressive to the fitting material
To create detachable threaded connections

Characteristics:

Thread male-male
Pipe cylindrical thread according to GOST 6357 (ISO 228, EN 10226)
Nominal pressure 17 to 40 bar
Execution material: hot-pressed brass of the CW 617N brand according to the EN 12165 standard
The maximum temperature of a working environment is up to +250 ºС

G	А	B	Weight
	mm	mm	kg/pc
3/4"	44	34	0,130

Download data sheet: VALTEC Threaded fittings

VALTEC Elbow, male-male, d - 1" [Code number: VTr.093.N.0006]

Details

VTr.093.N.0006

641 rub

Application purpose:

For cold water supply
For hot water
For heating
For domestic water supply systems
For compressed air systems
For technological pipelines
For pipelines transporting gases and liquids, non-aggressive to the fitting material
To create detachable threaded connections

Characteristics:

Thread male-male
Pipe cylindrical thread according to GOST 6357 (ISO 228, EN 10226)
Nominal pressure 17 to 40 bar
Execution material: hot-pressed brass of the CW 617N brand according to the EN 12165 standard
The maximum temperature of a working environment is up to +250 ºС

G	А	B	Weight
	mm	mm	kg/pc
1"	54	41	0,216

Download data sheet: VALTEC Threaded fittings

VALTEC threaded elbows of brass
