Fittings for heating systems

Home→ Catalog→ Heating systems→ Fittings for heating systems

The group of products includes various fittings for underfloor and central heating systems. So, fittings for heating systems include:

  • T-pieces and pipe crosses which are designed to combine several branches of the pipeline;
  • Bends are used when direction of the pipeline is required to change;
  • Manifolds;
  • Transitional elements which are used for connection pipes with different diameters or pipes of one material to pipes of another material;
  • Stop valves;
  • Manifold cabinets where you can hide the equipment of the heating system;
  • Elements of radiator layout for connection floor heating system to radiator;
  • Radiator connection systems skirtings which is used for hidden installation of the heating system etc.
Photo Name Article Price
Photo Draft
Photo [NO LONGER PRODUCED] - IBP B-Press Inox Tee - Equal, d - 76,1 [Code number: PS5130 076076076] Draft [NO LONGER PRODUCED] - IBP B-Press Inox Tee - Equal, d - 76,1 [Code number: PS5130 076076076]
[NO LONGER PRODUCED] - IBP B-Press Inox Tee - Equal, d - 76,1 [Code number: PS5130 076076076]
Details 		PS5130 076076076

Application purposes:

  • For heating and cooling systems
  • For water supply
  • For plumbing and drainage equipment
  • For industrial equipment

Characteristics:

  • Pressing connection

Material: Stainless steel

Maximum temperature ranges: from -50 °C to +150 °C

Maximum operating temperature: from -35 °C to +110 °C

d L A I
mm mm mm mm
76,1 - - -
Photo Draft
Photo Geberit Mapress Stainless Steel adapter with union nut, d76,1 [Code number: 35039] Draft Geberit Mapress Stainless Steel adapter with union nut, d76,1 [Code number: 35039]
Geberit Mapress Stainless Steel adapter with union nut, d76,1 [Code number: 35039]
Details 		35039

ATTENTION! This product is temporarily unavailable for order!

Application Purpose:

  • For sanitary and industrial applications
  • For heating installations

Characteristics:

  • Union nut made of brass
  • Flat sealed
  • Leaky if unpressed

Scope of delivery:

  • EPDM flat gasket
  • Seal ring CIIR black

Technical data

Material: Stainless Cr-Ni-Mo steel 1.4401 BS 316

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d G L Z
mm '' cm cm
76,1 3 9,9 3,3
Photo Draft
Photo [NO LONGER PRODUCED] - Geberit Mapress Stainless Steel elbow adapter 90° with female thread, LABS-free, d 28 [Code number: 83806] Draft [NO LONGER PRODUCED] - Geberit Mapress Stainless Steel elbow adapter 90° with female thread, LABS-free, d 28 [Code number: 83806]
[NO LONGER PRODUCED] - Geberit Mapress Stainless Steel elbow adapter 90° with female thread, LABS-free, d 28 [Code number: 83806]
Details 		83806

ATTENTION! This product is temporarily unavailable for order!

Application purposes:

  • For technical building systems, industry and shipbuilding

Characteristics:

  • Pressing indicator
  • Leaky if unpressed
  • Female thread

Scope of delivery:

  • Seal ring made of CIIR, black

Technical data

Product material: CrNiMo steel 1.4401 (EN 10088)

Elbow: 90°

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d Rp L L1 Z Z1
mm " cm cm cm cm
28 1 6.7 5.4 4.3 3.7
Photo Draft
Photo [NO LONGER PRODUCED] - IBP B-Press Inox Tee - Equal, d - 88,9 [Code number: PS5130 089089089] Draft [NO LONGER PRODUCED] - IBP B-Press Inox Tee - Equal, d - 88,9 [Code number: PS5130 089089089]
[NO LONGER PRODUCED] - IBP B-Press Inox Tee - Equal, d - 88,9 [Code number: PS5130 089089089]
Details 		PS5130 089089089

Application purposes:

  • For heating and cooling systems
  • For water supply
  • For plumbing and drainage equipment
  • For industrial equipment

Characteristics:

  • Pressing connection

Material: Stainless steel

Maximum temperature ranges: from -50 °C to +150 °C

Maximum operating temperature: from -35 °C to +110 °C

d L A I
mm mm mm mm
88,9 - - -
Photo Draft
Photo Geberit Mapress Stainless Steel adapter with union nut, d88,9 [Code number: 35040] Draft Geberit Mapress Stainless Steel adapter with union nut, d88,9 [Code number: 35040]
Geberit Mapress Stainless Steel adapter with union nut, d88,9 [Code number: 35040]
Details 		35040

ATTENTION! This product is temporarily unavailable for order!

Application Purpose:

  • For sanitary and industrial applications
  • For heating installations

Characteristics:

  • Union nut made of brass
  • Flat sealed
  • Leaky if unpressed

Scope of delivery:

  • EPDM flat gasket
  • Seal ring CIIR black

Technical data

Material: Stainless Cr-Ni-Mo steel 1.4401 BS 316

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d G L Z
mm '' cm cm
88,9 3 1/2 11,1 3,7
Photo Draft
Photo [NO LONGER PRODUCED] - Geberit Mapress Stainless Steel elbow adapter 90° with female thread, LABS-free, d 35 [Code number: 83807] Draft [NO LONGER PRODUCED] - Geberit Mapress Stainless Steel elbow adapter 90° with female thread, LABS-free, d 35 [Code number: 83807]
[NO LONGER PRODUCED] - Geberit Mapress Stainless Steel elbow adapter 90° with female thread, LABS-free, d 35 [Code number: 83807]
Details 		83807

ATTENTION! This product is temporarily unavailable for order!

Application purposes:

  • For technical building systems, industry and shipbuilding

Characteristics:

  • Pressing indicator
  • Leaky if unpressed
  • Female thread

Scope of delivery:

  • Seal ring made of CIIR, black

Technical data

Product material: CrNiMo steel 1.4401 (EN 10088)

Elbow: 90°

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d Rp L L1 Z Z1
mm " cm cm cm cm
35 1 1/4 7.5 6.3 4.9 4.4
Photo Draft
Photo [NO LONGER PRODUCED] - IBP B-Press Inox Tee - Reduced, d - 88,9 х 76,1 х 88,9 [Code number: PS5130 089076089] Draft [NO LONGER PRODUCED] - IBP B-Press Inox Tee - Reduced, d - 88,9 х 76,1 х 88,9 [Code number: PS5130 089076089]
[NO LONGER PRODUCED] - IBP B-Press Inox Tee - Reduced, d - 88,9 х 76,1 х 88,9 [Code number: PS5130 089076089]
Details 		PS5130 089076089

Application purposes:

  • For heating and cooling systems
  • For water supply
  • For plumbing and drainage equipment
  • For industrial equipment

Characteristics:

  • Pressing connection

Material: Stainless steel

Maximum temperature ranges: from -50 °C to +150 °C

Maximum operating temperature: from -35 °C to +110 °C

d L A I
mm mm mm mm
88,9 х 76,1 х 88,9 - - -
Photo Draft
Photo Geberit Mapress Stainless Steel adapter with male thread G, d 15 [Code number: 31731] Draft Geberit Mapress Stainless Steel adapter with male thread G, d 15 [Code number: 31731]
Geberit Mapress Stainless Steel adapter with male thread G, d 15 [Code number: 31731]
Details 		31731

ATTENTION! This product is temporarily unavailable for order!

Application purposes:

  • For drinking water and industrial applications
  • For heating installations

Characteristics:

  • Pressing indicator
  • Leaky if unpressed
  • Seal ring made of CIIR, black
  • Male thread

Technical data

Material: CrNiMo steel 1.4401 (EN 10088)

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d G H L
mm '' cm cm
15 3/4 1,5 3,5
Photo Draft
Photo Geberit Mapress CuNiFe bend adapter 90° with female thread, d 15 [Code number: 67503] Draft Geberit Mapress CuNiFe bend adapter 90° with female thread, d 15 [Code number: 67503]
Geberit Mapress CuNiFe bend adapter 90° with female thread, d 15 [Code number: 67503]
Details 		67503

ATTENTION! This product is temporarily unavailable for order!

Application Purpose:

  • For pipe systems carrying sea water
  • Not suitable for drinking water

Characteristics:

  • With pressing indicator
  • Leaky if unpressed
  • Female thread

Scope of delivery:

  • Seal ring CIIR black

Technical data

Material: CuNi10Fe1.6Mn, product material no. 2.1972.11

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d Rp L L1 Z Z1
mm '' cm cm cm cm
15 1/2 3,8 7,7 1,8 6,4
Photo Draft
Photo Geberit Mapress Stainless Steel adapter with male thread G, d 18 [Code number: 31732] Draft Geberit Mapress Stainless Steel adapter with male thread G, d 18 [Code number: 31732]
Geberit Mapress Stainless Steel adapter with male thread G, d 18 [Code number: 31732]
Details 		31732

ATTENTION! This product is temporarily unavailable for order!

Application purposes:

  • For drinking water and industrial applications
  • For heating installations

Characteristics:

  • Pressing indicator
  • Leaky if unpressed
  • Seal ring made of CIIR, black
  • Male thread

Technical data

Material: CrNiMo steel 1.4401 (EN 10088)

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d G H L
mm '' cm cm
18 3/4 1,7 3,8
Photo Draft
Photo Geberit Mapress CuNiFe bend adapter 90° with female thread, d 22, Rp1/2 [Code number: 67506] Draft Geberit Mapress CuNiFe bend adapter 90° with female thread, d 22, Rp1/2 [Code number: 67506]
Geberit Mapress CuNiFe bend adapter 90° with female thread, d 22, Rp1/2 [Code number: 67506]
Details 		67506

ATTENTION! This product is temporarily unavailable for order!

Application Purpose:

  • For pipe systems carrying sea water
  • Not suitable for drinking water

Characteristics:

  • With pressing indicator
  • Leaky if unpressed
  • Female thread

Scope of delivery:

  • Seal ring CIIR black

Technical data

Material: CuNi10Fe1.6Mn, product material no. 2.1972.11

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d Rp L L1 Z Z1
mm '' cm cm cm cm
22 1/2 4,7 8,6 2,6 7,3
Photo Draft
Photo IBP B-Press Connector With Flat Sealing Face, d - 88,9 x 3"1/2 [Code number: P4355 08928000] Draft IBP B-Press Connector With Flat Sealing Face, d - 88,9 x 3"1/2 [Code number: P4355 08928000]
IBP B-Press Connector With Flat Sealing Face, d - 88,9 x 3"1/2 [Code number: P4355 08928000]
Details 		P4355 08928000

Application purposes:

  • For heating systems and water applications
  • For gas pipelines
  • For solar collectors

Characteristics:

  • Flat sealing face

Material: copper

d Z S
mm mm mm
88,9 x 3"1/2 22 110
Photo Draft
Photo Geberit Mapress Stainless Steel adapter with male thread G, d 22 [Code number: 31733] Draft Geberit Mapress Stainless Steel adapter with male thread G, d 22 [Code number: 31733]
Geberit Mapress Stainless Steel adapter with male thread G, d 22 [Code number: 31733]
Details 		31733

ATTENTION! This product is temporarily unavailable for order!

Application purposes:

  • For drinking water and industrial applications
  • For heating installations

Characteristics:

  • Pressing indicator
  • Leaky if unpressed
  • Seal ring made of CIIR, black
  • Male thread

Technical data

Material: CrNiMo steel 1.4401 (EN 10088)

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d G H L
mm '' cm cm
22 1 1,9 4
Photo Draft
Photo Geberit Mapress CuNiFe bend adapter 90° with female thread, d 22, Rp3/4 [Code number: 67507] Draft Geberit Mapress CuNiFe bend adapter 90° with female thread, d 22, Rp3/4 [Code number: 67507]
Geberit Mapress CuNiFe bend adapter 90° with female thread, d 22, Rp3/4 [Code number: 67507]
Details 		67507

ATTENTION! This product is temporarily unavailable for order!

Application Purpose:

  • For pipe systems carrying sea water
  • Not suitable for drinking water

Characteristics:

  • With pressing indicator
  • Leaky if unpressed
  • Female thread

Scope of delivery:

  • Seal ring CIIR black

Technical data

Material: CuNi10Fe1.6Mn, product material no. 2.1972.11

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d Rp L L1 Z Z1
mm '' cm cm cm cm
22 3/4 4,7 8,8 2,6 7,3
Photo Draft
Photo Geberit Mapress Stainless Steel adapter with male thread G, d 28 [Code number: 31734] Draft Geberit Mapress Stainless Steel adapter with male thread G, d 28 [Code number: 31734]
Geberit Mapress Stainless Steel adapter with male thread G, d 28 [Code number: 31734]
Details 		31734

ATTENTION! This product is temporarily unavailable for order!

Application purposes:

  • For drinking water and industrial applications
  • For heating installations

Characteristics:

  • Pressing indicator
  • Leaky if unpressed
  • Seal ring made of CIIR, black
  • Male thread

Technical data

Material: CrNiMo steel 1.4401 (EN 10088)

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d G H L
mm '' cm cm
28 1 1/4 1,8 4,1
Photo Draft
Photo Geberit Mapress CuNiFe bend adapter 90° with female thread, d 28 [Code number: 67508] Draft Geberit Mapress CuNiFe bend adapter 90° with female thread, d 28 [Code number: 67508]
Geberit Mapress CuNiFe bend adapter 90° with female thread, d 28 [Code number: 67508]
Details 		67508

ATTENTION! This product is temporarily unavailable for order!

Application Purpose:

  • For pipe systems carrying sea water
  • Not suitable for drinking water

Characteristics:

  • With pressing indicator
  • Leaky if unpressed
  • Female thread

Scope of delivery:

  • Seal ring CIIR black

Technical data

Material: CuNi10Fe1.6Mn, product material no. 2.1972.11

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d Rp L L1 Z Z1
mm '' cm cm cm cm
28 1 5,7 9,7 4 7,8
Photo Draft
Photo Geberit Mapress Stainless Steel adapter with male thread G, d 35 [Code number: 31735] Draft Geberit Mapress Stainless Steel adapter with male thread G, d 35 [Code number: 31735]
Geberit Mapress Stainless Steel adapter with male thread G, d 35 [Code number: 31735]
Details 		31735

ATTENTION! This product is temporarily unavailable for order!

Application purposes:

  • For drinking water and industrial applications
  • For heating installations

Characteristics:

  • Pressing indicator
  • Leaky if unpressed
  • Seal ring made of CIIR, black
  • Male thread

Technical data

Material: CrNiMo steel 1.4401 (EN 10088)

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d G H L
mm '' cm cm
35 1 1/2 2,1 4,7
Photo Draft
Photo Geberit Mapress CuNiFe bend adapter 90° with female thread, d 35 [Code number: 67509] Draft Geberit Mapress CuNiFe bend adapter 90° with female thread, d 35 [Code number: 67509]
Geberit Mapress CuNiFe bend adapter 90° with female thread, d 35 [Code number: 67509]
Details 		67509

ATTENTION! This product is temporarily unavailable for order!

Application Purpose:

  • For pipe systems carrying sea water
  • Not suitable for drinking water

Characteristics:

  • With pressing indicator
  • Leaky if unpressed
  • Female thread

Scope of delivery:

  • Seal ring CIIR black

Technical data

Material: CuNi10Fe1.6Mn, product material no. 2.1972.11

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d Rp L L1 Z Z1
mm '' cm cm cm cm
35 1 1/4 6,8 11 4,2 9,1
Photo Draft
Photo Geberit Mapress Stainless Steel adapter with male thread G, d 42 [Code number: 31736] Draft Geberit Mapress Stainless Steel adapter with male thread G, d 42 [Code number: 31736]
Geberit Mapress Stainless Steel adapter with male thread G, d 42 [Code number: 31736]
Details 		31736

ATTENTION! This product is temporarily unavailable for order!

Application purposes:

  • For drinking water and industrial applications
  • For heating installations

Characteristics:

  • Pressing indicator
  • Leaky if unpressed
  • Seal ring made of CIIR, black
  • Male thread

Technical data

Material: CrNiMo steel 1.4401 (EN 10088)

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d G H L
mm '' cm cm
42 1 3/4 2,2 5,2
Photo Draft
Photo Geberit Mapress CuNiFe bend adapter 90° with female thread, d 42 [Code number: 67510] Draft Geberit Mapress CuNiFe bend adapter 90° with female thread, d 42 [Code number: 67510]
Geberit Mapress CuNiFe bend adapter 90° with female thread, d 42 [Code number: 67510]
Details 		67510

ATTENTION! This product is temporarily unavailable for order!

Application Purpose:

  • For pipe systems carrying sea water
  • Not suitable for drinking water

Characteristics:

  • With pressing indicator
  • Leaky if unpressed
  • Female thread

Scope of delivery:

  • Seal ring CIIR black

Technical data

Material: CuNi10Fe1.6Mn, product material no. 2.1972.11

Download the installation instructions: Installation of Geberit Mapress Geberit Mapress system

d Rp L L1 Z Z1
mm '' cm cm cm cm
42 1 1/2 8 12,3 5 10,4

© Inrusstrade.ru 1999-2024. "Inrusstrade" Ltd. Copying and quoting is prohibited
